8 Ton Inverter Water Chiller industrial chiller machine

8 Ton Inverter Water Chiller industrial chiller machine

Brand Name: ANGES
Model Number: Inverter Chiller
MOQ: 1
Detail Information
Place of Origin:
China
Type:
Water Cooled Inverter Chiller
Refrigerant:
R410a, R134a, R407c
Cooling Capacity:
8 Ton
Compressor Type:
Inverter Scroll Chiller
Pump:
2bar- 6bar
Evaporator:
Shell And Tube
Condenser:
Shell And Tube ,Plater Heat Exchanger
Application:
Industrial Cooling Solutions
Highlight:

8 Ton Inverter Water Chiller

,

Inverter Water Chiller 8 Ton

,

8 Ton industrial chiller machine

Product Description

Inverter Water Chiller Inverter Compressor Chiller Variable-Speed Chiller Inverter Chiller Energy Saving



How does the inverter compressor work in industrial water chiller?
The inverter compressor uses a variable frequency drive to slow down or speed up the motor that rotates the compressor. Inverter chillers are able to match the varying load requirements to control running speed of the compressor's motor continuously. With this technology, the inverter chillers with outstanding part load and seasonal efficiency, with a great energy saving solution.



By using the inverter compressor solutions, significant energy savings can be achieved compared to traditional on-off compressors or mechanically-modulated technologies.



Inverter Chiller Specification

Item

AWV-8
Nominal cooling capacity Low frequency kcal/h 5676
  High frequency kcal/h 20434
  Low frequency kw 6.6
  High frequency kw 23.76
Input power Low frequency kw 2.86
  High frequency kw 6.4
Power Variable frequency power supply
Refrigerant Type R410a
  Type of control Electronic expansion valve
Compressor Type Hermetic motor driven compressor
  Low frequency power( kw) 1.36
  High frequency power (kw) 4.9
Condenser Type Shell and tube
  Cooling water flow (m3/h) 4.9
  Inlet and outlet pipe caliber(inch) 1-1/2
Evaporator Type Water tank with coil
  Chilled water flow (m3/h) 4.1
T Tank volume(L) 150
  Inlet and outlet pipe caliber(inch) 1-1/2
Pump Power (kw) 1.5
  Lift(m) 22
Safety protection compressor over temperature, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing
Dimension mm 1320*710*1320
Weight kg 300


Features and benefits of industrial inverter chiller

  1. High efficiency and energy saving: The full frequency conversion drive technology greatly improves the comprehensive performance (IPLV) of the unit, and saves 30% electricity compared with the fixed-frequency unit.
  2. Precise temperature control: The inverter chiller controlled temperature of the chilled water is within 0.1 ° C, which meets the requirements of high precision temperature control.
  3. Faster cooling speed: Compared with the fixed frequency chiller,the inverter chiller cooling time is increased by 50%.
  4. Long life of compressor: Frequency conversion compressor runs at low speed load most of the time, less wear.
  5. Small starting current: The inverter chiller starts at low frequency and low voltage, so the starting current is small and the interference to the power grid is small.

Chiller service

We are industrial chiller manufacturer, chiller service can be online support, video technical support, site service in some areas are available.

Site service will be done by our water chiller distributor, Indonesia, Philippines, Thailand, Singapore, Malaysia, Australia, United States, Israel, Egypt and so on.



How to select the model of the chiller ?

  • We need to know the heat load of your process or chiller cooling capacity.
  • Required water temperature, water pressure and flow rate.
  • Application and power supply in local.
  • Max. Ambient temperature in summer day
  • Customized special specifications are acceptable. Contact us for more chiller specification.We have a professional team to provide you with the best solution.
