Inverter Chiller
>
Water Chiller Systems Inverter Scroll Chiller Small Industrial

Water Chiller Systems Inverter Scroll Chiller Small Industrial

Brand Name: ANGES
Model Number: Inverter Chiller
MOQ: 1
Detail Information
Place of Origin:
China
Type:
Water Cooled Inverter Chiller
Refrigerant:
R134a/R407c/R410a
Cooling Capacity:
30HP
Compressor Type:
Inverter Scroll Chiller
Pump:
2bar- 6bar
Evaporator:
Shell And Tube
Condenser:
Shell And Tube ,Plater Heat Exchanger
Application:
Industrial Cooling Solutions
Highlight:

Small inverter scroll chiller

,

inverter scroll chiller Industrial

,

30HP Water Chiller Systems

Product Description

Water Chiller Systems Scroll Chiller PackageWater Cooled Chiller System Plant Danfoss Scroll Small Industrial Chiller



About the inverter chiller

Inverter Compressor Chiller- Variable frequency, high efficiency,energy saving and consumption reduction.

With Variable Frequency Drive (VFD) technology, chillers are able to match the varying load requirements to control running speed, regardless of requirement. By using the inverter compressor solutions, significant energy savings can be achieved compared to traditional on-off compressors or mechanically-modulated technologies.



Specification

Item

AWV-30(T)
Nominal cooling capacity Low frequency kcal/h 22178
  High frequency kcal/h 79842
  Low frequency kw 25.79
  High frequency kw 92.84
Input power Low frequency kw 8.2
  High frequency kw 21.73
Power Variable frequency power supply
Refrigerant Type R410a
  Type of control Electronic expansion valve
Compressor Type Hermetic motor driven compressor
  Low frequency power( kw) 5.2
  High frequency power (kw) 18.73
Condenser Type Shell and tube
  Cooling water flow (m3/h) 16
  Inlet and outlet pipe caliber(inch) 2-1/2
Evaporator Type Water tank with coil
  Chilled water flow (m3/h) 16
T Tank volume(L) 445
  Inlet and outlet pipe caliber(inch) 2-1/2
Pump Power (kw) 3
  Lift(m) 22
Safety protection compressor over temperature, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing
Dimension mm 2030*910*1820
Weight kg 1150


Features and benefits

Variable-speed chillers offer an alternative for process cooling applications. They use variable-speed compressors coupled with advanced PLCs. The controller continuously monitors the heat load and adjusts the compressor speed for peak efficiency and temperature control.

  1. Energy saving. Inverter technology can ensure the best chiller performance. Chillers are able to run according to the heat load by adjust th speed of the compressor’s motor continuously which can result in consistent saving in operating costs.
  2. Capacity modulation adapts motor speed to vary load continuously, quickly, and smoothly for great comfort and reliability.
  3. Accurate temperature control. Advanced DC frequency conversion control technology is adopted to achieve high control accuracy, and the temperature control accuracy can reach ±0.1℃-±0.2℃.
  4. Low starting current.Frequency conversion soft start reduce the the impact of the power grid start, reduce the power distribution costs, safe and reliable in operation.
  5. Low acoustic level with variable-speed technology
  6. The COP efficiency of water-cooled chiller is relatively high, which is used in industrial process cooling and large-scale construction projects.

Chiller service

We are industrial chiller manufacturer, chiller service can be online support, video technical support, site service in some areas are available.

Site service will be done by our water chiller distributor, Indonesia, Philippines, Thailand, Singapore, Malaysia, Australia, United States, Israel, Egypt and so on.
