| Brand Name: | ANGES |
| Model Number: | Inverter Chiller |
| MOQ: | 1 |
Water Chiller Portable Wate Chiller Inverter Energy Efficient Chiller VFD Chiller Inverter Compressor
About the inverter chiller
Water chiller with non-inverter type compressor remains constant water temperature by adjusting the compressor's ON and OFF, which consumes more energy.
In inverter type water chiller,water temperature is adjusted by changing compressor motor speed instead of ON and OFF.
Compared to non-inverter type water chiller, the inverter chiller has less power loss and can save in energy.
Variable-speed chillers offer an alternative for process cooling applications.The controller continuously monitors the heat load from the production process to slow down or speed up the compressor motor for peak efficiency and temperature control.
Water Chiller Specification
|
Item |
AWV-15(D) | |
| Nominal cooling capacity | Low frequency kcal/h | 11352 |
| High frequency kcal/h | 40867 | |
| Low frequency kw | 13.2 | |
| High frequency kw | 47.52 | |
| Input power | Low frequency kw | 4.22 |
| High frequency kw | 11.30 | |
| Power | Variable frequency power supply | |
| Refrigerant | Type | R410a |
| Type of control | Electronic expansion valve | |
| Compressor | Type | Hermetic motor driven compressor |
| Low frequency power( kw) | 2.72 | |
| High frequency power (kw) | 9.80 | |
| Condenser | Type | Shell and tube |
| Cooling water flow (m3/h) | 9.8 | |
| Inlet and outlet pipe caliber(inch) | 2 | |
| Evaporator | Type | Water tank with coil |
| Chilled water flow (m3/h) | 8.2 | |
| T | Tank volume(L) | 350 |
| Inlet and outlet pipe caliber(inch) | 2 | |
| Pump | Power (kw) | 1.5 |
| Lift(m) | 20 | |
| Safety protection | compressor over temperature, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing | |
| Dimension | mm | 1850*810*1620 |
| Weight | kg | 735 |
Features and benefits
Chiller service
We are industrial chiller manufacturer, chiller service can be online support, video technical support, site service in some areas are available.
Site service will be done by our water chiller distributor, Indonesia, Philippines, Thailand, Singapore, Malaysia, Australia, United States, Israel, Egypt and so on.
|
|
