| Brand Name: | ANGES |
| Model Number: | Inverter Chiller |
| MOQ: | 1 |
Industrial Water Chiller Energy Efficien Chiller Variable Frequency Chiller Portable Chiller Inverter Water Chiller
About the inverter chiller
An inverter chiller use inverter compressor with a variable frequency drive to slow down or speed up the motor running according to the heat load from production process.It can reduce wasted operation during industrial process cooling by efficiently controlling motor speed.The controller continuously monitors the heat load of the production process and adjusts the compressor speed for peak efficiency and temperature control.
Industrial water chiller specification
|
Item |
AWV-20(D) | |
| Nominal cooling capacity | Low frequency kcal/h | 14786 |
| High frequency kcal/h | 53228 | |
| Low frequency kw | 17.19 | |
| High frequency kw | 61.89 | |
| Input power | Low frequency kw | 5.67 |
| High frequency kw | 14.69 | |
| Power | Variable frequency power supply | |
| Refrigerant | Type | R410a |
| Type of control | Electronic expansion valve | |
| Compressor | Type | Hermetic motor driven compressor |
| Low frequency power( kw) | 3.47 | |
| High frequency power (kw) | 12.49 | |
| Condenser | Type | Shell and tube |
| Cooling water flow (m3/h) | 12.8 | |
| Inlet and outlet pipe caliber(inch) | 2 | |
| Evaporator | Type | Water tank with coil |
| Chilled water flow (m3/h) | 10.7 | |
| Tank | Tank volume(L) | 350 |
| Inlet and outlet pipe caliber(inch) | 2 | |
| Pump | Power (kw) | 2.2 |
| Lift(m) | 20 | |
| Safety protection | compressor over temperature, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing | |
| Dimension | mm | 1850*810*1620 |
| Weight | kg | 820 |
Features and benefits of industrial inverter chiller
Why do I need a industrial water chiller?
Industrial chillers are used for controlled cooling of products, mechanisms and machinery in a variety of industries. A chiller removes heat from the process water and transfers it to air via a heat exchanger.Industrial water chiller can keep your equipment at a safe operating temperature and cool your components during processes to ensure the highest quality final products and reduce production cycle time.
How to select the model of the chiller ?
Chiller service
We are industrial chiller manufacturer, chiller service can be online support, video technical support, site service in some areas are available.
Site service will be done by our water chiller distributor, Indonesia, Philippines, Thailand, Singapore, Malaysia, Australia, United States, Israel, Egypt and so on.
|
|
