5HP Air-Cooled Chiller | Energy-Saving, Quiet Operation, Smart Temperature Control – Efficient Industrial Cooling Solution

5HP Air-Cooled Chiller | Energy-Saving, Quiet Operation, Smart Temperature Control – Efficient Industrial Cooling Solution

Product Overview:

The 5HP Air-Cooled Chiller is a high-efficiency cooling solution designed for small-to-medium industrial applications. Utilizing eco-friendly refrigerants and advanced air-cooling technology, it eliminates the need for external cooling towers, offering easy installation and precise temperature control for industries such as injection molding, laser processing, food manufacturing, and laboratories.

Key Selling Points:

1. Energy-Efficient & Cost-Effective:
   • Equipped with a high-efficiency compressor (EER≥3.5), saving over 20% energy compared to conventional models.
   • Smart start/stop function adjusts operating frequency based on load, minimizing wasted energy.
2. Ultra-Quiet & Environmentally Friendly:
   • Optimized air duct design reduces noise to ≤65dB(A), comparable to a library environment.
   • Vibration-absorbing pads and sound-insulating cotton minimize mechanical noise.
3. Smart Temperature Control & Precision:
   • 7-inch touchscreen + PLC control system supports ±1℃ temperature accuracy.
   • Remote monitoring interface (optional 4G module) for real-time equipment status tracking.

Technical Specifications:

• Cooling Capacity: 5HP (14kW)
• Temperature Range: 5℃~35℃ (customizable down to -10℃~20℃)
• Cooling Method: Air-cooled with high-efficiency axial fans
• Compressor Type: Fully hermetic scroll compressor
• Power Supply: 380V/50Hz (220V single-phase optional)
• Dimensions: 1140×560×1250mm (L×W×H)

Applications:

• Injection Molding: Cooling molds and hydraulic oil to shorten cycle times.

• Laser Processing: Stabilizing laser temperatures for extended equipment life.

• Food Manufacturing: Low-temperature storage and blast freezing tunnel cooling.

• Laboratories: Biological sample refrigeration and precision instrument cooling.

Product Advantages:

• Easy Installation: No cooling tower or water circuit required; plug-and-play.

• Low Maintenance: Modular design for quick replacement of faulty components.

• Reliable Safety: Multiple protections (high/low pressure, overload, phase loss) ensure safe operation.

•
