Name: 280HP Water Cooled Screw Chiller Industrial Process Water Chillers For Printing And BOPP Film Lamination Line
Brand: Shenzhen Anges Machinery Co., Ltd
SKU: 280hp
Price: 2,100.00 USD
Availability: InStock

Home > products > Industrial Water Chiller >

280HP Water Cooled Screw Chiller Industrial Process Water Chillers For Printing And BOPP Film Lamination Line

280HP Water Cooled Screw Chiller

Industrial Process Water Cooled Screw Chiller

Water Chillers For Printing

Place of Origin:

China

Brand Name:

ANGES

Model Number:

280hp

Request A Quote

Product Details

Weight:

4560kg

Compressor Tpye:

Screw Compressor

Original:

China Chiller Manufacturer

Warranty:

1 Year

Machine Size:

4250*1320*2150mm

Cooling Method:

Water-cooled

Compressor Power:

105.8*2kW

Highlight:

280HP Water Cooled Screw Chiller

Industrial Process Water Cooled Screw Chiller

Water Chillers For Printing

Payment & Shipping Terms

Minimum Order Quantity

Packaging Details

Plywood case

Delivery Time

30 days

Payment Terms

L/C, T/T

Compact Water-Cooled Chillers 6ton Rapid Cooling with 19kw Cooling Capacity 24/7 Remote Monitoring Eco-Friendly Refrigerant

Get Best Price

Contact Now

Product Description

Shenzhen Anges Machinery Co., Ltd

Technical Parameter of Water-Cooled Screw Type Chiller

Model Item		AGS-280WDH
Nominal cooling capacity	kcal/h	915040
Nominal cooling capacity	kw	1064
Input power	kw	212
Max running current	A	482.3
Power supply	3PH-380V-50HZ
Refrigerant	Type	R22
Refrigerant	Type of control	expansion valve
Compressor	Type	semi-hermetic screw
	Power(kw)	105.8×2
	Start-up mode	Y-△
	Capacity control	0-25-50-75-100
Evaporator	Type	shell and tube
	Chilled fluid flow (m³/h)	183
	Pipe diameter (inch)	6
Condenser	Type	shell and tube
	Cooling water flow (m³/h)	219
	Pipe diameter (inch)	5×2
Safety protection	compressor over temperature protection, over load protection, high and low pressure protection, flow switch protection, reversed and lacking phase protection, anti-freezing protection,fusible protection.
Dimension	mm	425013202150
Net weight	kg	4230
Running weight	kg	4560

Note: 1.Nominal cooling capacity is according to:

Inlet chilled fluid temperature: 17℃; Outlet chilled fluid temperature: 12℃

Inlet cooling water temperature: 30℃; Outlet cooling water temperature: 35℃

2. Working Range:

The temperature range of chilled fluid is from 5℃ to 35℃;

Temperature difference between inlet and outlet chilled fluid is from 3℃ to 8℃.

The temperature range of cooling water is from 18℃ to 37℃;

Temperature difference between inlet and outlet cooling water is from 3.5℃ to 10℃.

We reserve the right to modify the above dimensions or parameters without further notice.

Shenzhen Anges Machinery Co., Ltd

Configuration table for Water-cooled Screw Type Chiller

Item	Main Parts	Brand	Remark
1	Semi-hermetic Compressor	Hanbell	China
2	Expansion Valve	Emerson	USA
3	Condenser	Anges	China
4	Evaporator	Anges	China
6	Solenoid Valve	Emerson	USA
7	Drying Filter	Emerson	USA
8	Oil Pressure Gauge (High&Low)	Refco	Switzerland
9	Touch Screen	Weintek	China
10	PLC Controller	Siemens	Germany
11	Electrical components	Schneider	France
