3 Hp Air Cooled Chiller For A Semi-Automatic Blowing Machine For Bottles From 0.2 To 2.00 Lt
The 3Hp air-cooled scroll compressor is specifically designed for use in blow molding machines, particularly for the bottling industry. This high-performance compressor is engineered to provide reliable and efficient air compression, ensuring a consistent and stable air supply for the blow molding process.
Operating on an air-cooled principle, this compressor eliminates the need for a cooling system using water or other liquids, making it a more compact and portable option. The scroll design offers quiet operation and smooth compression, minimizing vibrations and wear and tear, which translates to longer equipment lifespan and reduced maintenance costs.
With a capacity of 3 horsepower (Hp), this compressor is capable of delivering sufficient air pressure and volume to meet the demands of blow molding machines, ensuring high-quality bottle production. It is suitable for a wide range of bottle sizes and materials, making it a versatile addition to any bottling operation.
Overall, the 3Hp air-cooled scroll compressor is a reliable and efficient choice for blow molding machines, offering consistent performance, reduced maintenance, and a compact footprint. Its ability to provide a stable air supply ensures high-quality bottle production, making it an essential component for any bottling facility.
Air-cooled Chiller Features
Industrial Chiller Specification:
|
Model Item |
ACK-3 | |
| Nominal cooling capacity | Kcal/h | 7955 |
| kw | 8.5 | |
| Input power | kw | 3.2 |
| Power supply | 3PH~380V/50HZ | |
| Refrigerant | Type | R22(R407c, R410a) |
| Type of control | Expansion valve | |
| Compressor | Type | Hermetic scroll type |
| Power (kw) | 2.64 | |
| Condenser | Type |
Finned copper tube+low noise outer rotor fan |
| Power(kw) | 0.19 | |
| Cooling air flow(m3 /h) | 3000 | |
| Evaporator | type | Shell and tube |
| Chilled water flow(m3 /h) | 1.47 | |
| Tank volume(L) | 20 | |
| Inlet/outlet pipe chiller(inch) | 1 | |
| Water pump | Power(kw) | 0.37 |
| Lift(m) | 20 | |
| Safety protection | compressor over temperature, over-current protection, high and low pressure protection, over -temperature protection ,flow switch protection,phase sequence or missing phase protection,exhaust overheating protection | |
| Net weight | kg | 150 |
| Dimension | mm | 1030*520*1185 |
Product Highlights
FAQ
Q: Can The air-cooled chiller Be Customized ?
A: Of course, we will carefully customize the air cooling chiller according to your requirements, and then conduct in-depth analysis.Finally, we promise to meet your expectations for this customization.
Q: How To Guarantee The Quality Of water cooling chiller ?
|
|
