| Brand Name: | ANGES |
| Model Number: | 12hp |
| MOQ: | 1 |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T |
Technical Parameters of Industrial Air-Cooled Chiller ACK-12
|
Item
Model |
ACK-12 | |
| nominal cooling capacity | kcal/h | 30014 |
| kw | 36.6 | |
| input power | kw | 11.72 |
| power supply | 3PH-415V-50HZ | |
| refrigerant | type | R22 |
| type of control | Expansive valve | |
| compressor | type | hermetic scroll |
| power(kw) | 9.3 | |
| condenser | type | finned copper tube + low noise outer rotor fan |
| power(kw) | 0.92 | |
| cooling air flow(m3/h) | 12000 | |
| evaporator | type | Shell and tube |
| chilled fluid flow(m3/h) | 6.31 | |
| volume(L) | 85 | |
| Inlet/outlet pipe caliber(inch) | 2 | |
| pump | power(kw) | 1.5 |
| flow (m3/h) | 12.5 | |
| lift(m) | 20 | |
|
Safety protection |
compressor over temperature protection, over load protection, high and low pressure protection, flow switch protection, reversed and lacking phase protection, anti-freezing protection, fusible protection. | |
| weight | kg | 550 |
| dimension | mm | 1530*780*1630 |
Note: 1. Nominal cooling capacity is according to:
Inlet chilled fluid temperature: 17℃; Outlet chilled fluid temperature: 12℃
Inlet cooling air temperature: 30℃; Outlet cooling air temperature: 35℃
2. Working range:
The temperature range of chilled fluid is from 5℃ to 35℃;
Temperature difference between inlet and outlet chilled fluid is from 3℃ to 8℃.
It is better to use the chiller while the ambient temperature at or below 35℃.
We reserve the right to modify the above dimensions or parameters without further notice.
Configuration table for ANGES industrial Chiller
| Parts | Brand | Remark |
| Compressor | Panasonic | Japan |
| Evaporator | ANGES | China |
| Condenser | ANGES | China |
| Expansion valve | Emerson | USA |
| Drying Filter | Danfoss | Denmark |
| Controller PCB | Punp | China |
| Electric Components | Schneider | France |
| Pressure Controller | Fensheng | China |
| Oil Pressure Gauge | JIUNAI | China |
| Pump | CNP | China |
| Fan | MAER | China |
|
|
| Brand Name: | ANGES |
| Model Number: | 12hp |
| MOQ: | 1 |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T |
Technical Parameters of Industrial Air-Cooled Chiller ACK-12
|
Item
Model |
ACK-12 | |
| nominal cooling capacity | kcal/h | 30014 |
| kw | 36.6 | |
| input power | kw | 11.72 |
| power supply | 3PH-415V-50HZ | |
| refrigerant | type | R22 |
| type of control | Expansive valve | |
| compressor | type | hermetic scroll |
| power(kw) | 9.3 | |
| condenser | type | finned copper tube + low noise outer rotor fan |
| power(kw) | 0.92 | |
| cooling air flow(m3/h) | 12000 | |
| evaporator | type | Shell and tube |
| chilled fluid flow(m3/h) | 6.31 | |
| volume(L) | 85 | |
| Inlet/outlet pipe caliber(inch) | 2 | |
| pump | power(kw) | 1.5 |
| flow (m3/h) | 12.5 | |
| lift(m) | 20 | |
|
Safety protection |
compressor over temperature protection, over load protection, high and low pressure protection, flow switch protection, reversed and lacking phase protection, anti-freezing protection, fusible protection. | |
| weight | kg | 550 |
| dimension | mm | 1530*780*1630 |
Note: 1. Nominal cooling capacity is according to:
Inlet chilled fluid temperature: 17℃; Outlet chilled fluid temperature: 12℃
Inlet cooling air temperature: 30℃; Outlet cooling air temperature: 35℃
2. Working range:
The temperature range of chilled fluid is from 5℃ to 35℃;
Temperature difference between inlet and outlet chilled fluid is from 3℃ to 8℃.
It is better to use the chiller while the ambient temperature at or below 35℃.
We reserve the right to modify the above dimensions or parameters without further notice.
Configuration table for ANGES industrial Chiller
| Parts | Brand | Remark |
| Compressor | Panasonic | Japan |
| Evaporator | ANGES | China |
| Condenser | ANGES | China |
| Expansion valve | Emerson | USA |
| Drying Filter | Danfoss | Denmark |
| Controller PCB | Punp | China |
| Electric Components | Schneider | France |
| Pressure Controller | Fensheng | China |
| Oil Pressure Gauge | JIUNAI | China |
| Pump | CNP | China |
| Fan | MAER | China |
