60HP Industrial Air Cooled Water Chiller with Large 345L/750L Stainless Steel Water Tank for Injection Molding Machine

60HP Industrial Air Cooled Water Chiller with Large 345L/750L Stainless Steel Water Tank for Injection Molding Machine

60HP Industrial Air Cooled Water Chiller

Injection Molding Machine Water Chiller

Place of Origin:

China

Brand Name:

Anges/SZAGS

Certification:

CE/ISO9001

Model Number:

ACK-60(F)

Contact Us

Request A Quote
Product Details
Compressor Type:
Hermetic Scroll
Water Tank Material:
Stainless Steel
Auto Shut-Off:
Yes
Compressor Tpye:
Scroll Compressor
Type:
Portable
Water Tank:
Included 345L
Water Tanl:
345L/750L
Cooling Type:
Finned Copper Tube + Low Noise Outer Rotor Fan
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Can be negotiate
Packaging Details
Standard export wooden box
Delivery Time
7~30days
Payment Terms
TT/LC/CASH
Supply Ability
Strong
Product Description

Product Description:

The Portable Liquids Chiller is constructed with a stainless-steel water tank material, ensuring durability and longevity. This 345L/750L water tank chiller is compactly designed to fit in small spaces, with dimensions of 2200mm*2050mm*1850mm.

One of the features that sets our Portable Liquids Chiller apart from others is the auto shut-off function. This function ensures that the chiller shuts off automatically when the desired temperature is reached, preventing any damage that could be caused by over-cooling.

Our Portable Liquids Chiller is perfect for any application that requires portable liquid cooling, from medical laboratories to industrial processes. This Portable Liquid Cooling Machine is easy to operate and can be transported easily from one location to another.

With our Portable Liquids Chiller, you can be confident that your liquids will be cooled to your desired temperature quickly and efficiently. The Hermetic Scroll compressor type ensures that the chiller runs smoothly and quietly, making it ideal for any setting.

Invest in our Portable Liquids Chiller today and experience the benefits of having a reliable and efficient cooling solution at your fingertips. Whether you need it for medical purposes or industrial processes, our Portable Liquids Chiller is the perfect solution for you.



Features:

  • Product Name: Portable Water Chiller
  • Brand: ANGES/SZAGZ
  • Cooling Capacity: 60HP
  • Compressor Type: Hermetic Scroll
  • Water Tank: Included 345L
  • Cooling Type: Finned Copper Tube + Low Noise Outer Rotor Fan
  • Compact Water Chiller: Yes
  • Lightweight Water Chiller: Yes


Technical Parameters of Industrial Air-cooled Chiller:

Model

Item

ACK-60(F)
nominal cooling capacity kcal/h 158928
kw 184.8
input power kw 57.48
power supply 3PH 380V 50Hz
refrigerant type R407C
type of control thermostatic expansion valve
compressor type hermetic scroll
power (kw) 49.8
condenser type finned copper tube + low noise outer rotor fan
cooling air flow (m3/h) 60000
evaporator type shell and tube
chilled fluid flow (m3/h) 31.86
volume(L) 345
inlet and outlet pipe diameter (inch) 3"
pump power (kw) 4
lift (m) 23
safety protection Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection,flow switch protection, phase sequence or missing phase protection, exhaust overheating protection
weight kg 2700
dimension mm 2200*2050*1850



Note: 1. Nominal cooling capacity is according to:

Inlet chilled fluid temperature: 17℃

Outlet chilled fluid temperature: 12℃

Inlet cooling air temperature: 30℃

Outlet cooling air temperature: 35℃

2. Working range:

The temperature range of chilled fluid is from 5℃ to 35℃;

Temperature difference between inlet and outlet chilled fluid is from 3℃ to 8℃.

The machine should be used the chiller while the ambient temperature at or below 40℃.

We reserve the right to modify the above dimensions or parameters without further notice.



Applications:

One key application for the Water Chiller is in the medical industry. This product is perfect for cooling medical equipment and supplies that require constant temperatures. It is also ideal for hospitals, clinics, and other medical facilities that require a reliable and portable water chiller.

In the food and beverage industry, the Portable Water Chiller is perfect for cooling liquids used in food production and storage. It is also ideal for outdoor events and catering, where a portable and reliable water chiller is required.

Another application for the Portable Water Chiller is in the manufacturing industry. This product is ideal for cooling machinery and equipment that require constant temperatures. It is also perfect for laboratories, research facilities, and universities that require a reliable and portable water chiller.

Industrial Water Chiller is manufactured in China and comes with CE/ISO9001 certification. The minimum order quantity is 1, and the price can be negotiated. The packaging details include a standard export wooden box, and the delivery time is 7~30 days. Payment terms include TT/LC/CASH, and the supply ability is strong.

Portable Water Chiller is equipped with finned copper tube and low noise outer rotor fan for efficient cooling. The water tank comes in two sizes - 345L and 750L, with the 345L tank included in the package. The ANGES/SZAGZ brand ensures quality and reliability in every product.



Support and Services:

The Portable Water Chiller product technical support and services include:

  • Expert technical assistance for installation and operation
  • Comprehensive user manuals and documentation
  • Regular maintenance and servicing options
  • Repairs and replacement parts
  • Training and education on product features and capabilities
  • 24/7 customer support for urgent issues


Packing and Shipping:

  • One Portable Water Chiller unit
  • User manual and warranty information
