Therefore, it is very important to choose an efficient chiller.
Anges specializes in milk cooling systems for the dairy industry
Chiller Specification
|
Model |
ACK-60(F) | |
| Nominal cooling capacity | Kcal/h | 152048 |
| kw | 184.8 | |
| Input power | kw | 57.48 |
| Power supply | 3PH~220V/60HZ | |
| Refrigerant | Type | R22 |
| Type of control | Expansion valve | |
| Compressor | Type | Hermetic scroll type |
| Power (kw) | 49.8 | |
| Condenser | Type |
Finned copper tube+low noise outer rotor fan |
| Power(kw) | 3.68 | |
| Cooling air flow(m3 /h) | 60000 | |
| Evaporator | type | Shell and tube |
| Chilled water flow(m3 /h) | 31.86 | |
| Tank volume(L) | 345 | |
| Inlet/outlet pipe chiller(inch) | 3 | |
| Water pump | Power(kw) | 4 |
| Lift(m) | 23 | |
| Safety protection | compressor over temperature, over-current protection, high and low pressure protection, over -temperature protection ,flow switch protection,phase sequence or missing phase protection,exhaust overheating protection | |
| Net weight | kg | 1850 |
| Dimension | mm | 2700*2200*2050 |
Anges chiller Application Range.
Food industry:such as cooling milk, etc
Benefit of Plastic Process Chiller Applications
How to select the model of the chiller ?
1. We need to know the heat load of your process or chiller cooling capacity, it can be calculated roughly according to production capacity.
2. Required water temperature, water pressure and flow rate.
3. Application and power supply in local.
4. Max. Ambient temperature in summer day
5. Customized special specifications are acceptable. Contact us for more chiller Specification by number +86 13923791048.
