| Brand Name: | ANGES |
| Model Number: | 35ton |
| MOQ: | 0 |
| Price: | Negotiable |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T, L/C, T/T, L/C |
35 ton water-cooled chiller Danfoss scroll compressor with shell and tube evaporator
Water cooled chiller
Anges chillers are divided into two types: air-cooled chillers and water-cooled chillers.
Chillers can be divided into low-temperature chillers and normal-temperature chillers according to temperature control.
Normal-temperature chillers generally control the water temperature between 0 and 35 degrees Celsius.
Low-temperature chillers usually control the temperature between 0 and minus 30 degrees Celsius.
We have strong design expertise and have partnerships with various plastic industries.
Specification for chilled water system
|
Model Item |
AC-40F | |
| Nominal cooling capacity | ton | 35 |
| kW | 120.4 | |
| Input power | kW | 39.2 |
| Power supply | 3PH~380V/50HZ | |
| Refrigerant | Type | R407C/R22/R134a/R410a |
| Type of control | Expansion valve | |
| Compressor | Type | Hermetic scroll type |
| Power (kw) | 32.4 | |
| Condenser | Type | Finned copper tube+low noise fan |
| Cooling air flow(m3/h) | 40000 | |
| Evaporator | Type | Shell and tube |
| Chilled water flow(m3/h) | 20.76 | |
| Inlet/outlet pipe chiller(inch) | 2-1/2 | |
| Safety protection | Compressor over temperature, over-current protection, high and low pressure protection, over -temperature protection ,flow switch protection,phase sequence or missing phase protection,exhaust overheating protection | |
| Net weight | kg | 1450 |
| Dimension | mm | 2100*1660*2070 |
Characteristics of Anges water-cooled Screw Chillers
The 35-ton water-cooled chiller unit utilizes a reputable brand scroll compressor and refrigerant circuit, offering low energy consumption, extended longevity, and superior stability.
Ideal for central cooling systems, this chiller efficiently cools various processes with easy installation, operation, and maintenance.
An efficient shell-and-tube evaporator ensures outstanding refrigeration performance and low condensing temperatures, making it an excellent choice for medium to large-scale refrigeration systems.
Additionally, we offer specialized high-temperature designs for optimal performance in hot weather conditions.
The digital intelligent temperature control device is another highlight, accurately measuring and controlling water temperatures between 5 to 35 degrees Celsius.
The chiller's protection system encompasses comprehensive features such as compressor overheating protection, high and low-pressure protection, phase sequence protection, flow protection, and antifreeze protection.
We also provide customized solutions for the pharmaceutical industry, delivering the best results tailored to your specific needs. Our solutions are unique and designed to meet your requirements.
Advantages of Anges Industrial Chillers:
The system maintains constant and precise control over process temperatures.
It enables direct delivery of coolant to the heat source of the application, enhancing production speed and efficiency through its precise temperature control capabilities.
The system ensures the highest quality of the final product.
Additionally, the cooling system prevents damage to heat-sensitive industrial components and minimizes unplanned maintenance downtime, which could otherwise halt the production process entirely.
Characteristics and Advantages of the Anges Chiller Unit:
High cooling capacity of up to 35 tons.
Temperature control range from 5°C to 35°C.
Panasonic/Danfoss scroll compressors.
Compact design, energy-saving, and easy maintenance.
Long warranty period of up to 12 months after purchase.
|
|
