High Efficiency Air Cooled Screw Chiller 100HP with Double Compressors CE ISO9001

Air Cooled Process Water Chiller Packaged Cooled Chiller System High Efficiency Chiller Plant Water Chiller

Applications of chilled water system

Chiller is a kind of cold water equipment that can provide cold water with constant temperature, flow rate and water pressure.

Water chiller is widely used in plastic industry, it is a critical part for injection molding production process, to transfer heat away from the mold and maintain a stable cooling rate, ensuring the highest quality final products.

Air-cooled screw chiller specification

Air-cooled screw chiller featurers

1. Adopting high-efficiency and energy-saving compressors of world class grade brands, high-quality condensers and evaporators, high cooling efficiency, stable performance, low noise and long service life.

2. The control system is adopting Siemens PLC controller and LCD touch screen , accurately controls the cooling capacity and cooling load of the unit in real time to achieve the best matching state, to ensure that the unit runs at the best efficiency and to reduce operating costs.

3. Screw compressor chiller capacity control can adopt four-stage (100%-75%-50%-25%), three-stage (100%-66%-33%) or stepless control system.

4. High-efficiency internally threaded copper pipes enhance the heat transfer effect are more energy efficient.

5. The machine is all made of oshell and tube evaporator and condenser, the welded structure is simple, sturdy structure, high quality, compact structure, long life and so on.

Advantages of Air-Cooled Chillers

• Easy Installation – Air-cooled chillers do not require a cooling tower or additional water piping, making them easier and more cost-effective to install.

• Lower Maintenance – Since there is no need for a cooling tower, air-cooled chillers eliminate issues like water treatment, scaling, and algae growth, reducing maintenance costs.

• Flexible Placement – Air-cooled chillers can be installed outdoors without the need for a dedicated mechanical room, making them ideal for locations with limited indoor space.

• Water Conservation – Unlike water-cooled systems, air-cooled chillers do not require continuous water supply, helping to conserve water resources and lower utility costs.

• Reliable Performance – With fewer components like cooling towers and water pumps, air-cooled chillers have a simpler system structure, reducing the risk of failures and ensuring stable operation.
