6ton Water Chiller 6hp Central Water Chiller Water Cooled Scroll Chiller Industrial Water Chiller Cooling System
About the portable chiller and central chiller
The portable chiller contains scroll chiller compressor refrigeration circuit, water tank and the pump and all necessary components. It can work after connecting the production lines with water pipes.
The water chiller cooling capacity is from 3kw -180kw, can accurately control the process temperature and shorten the cycle, increase the product quality and improve the production efficiency.
Specification for chilled water system
|
Model Item |
AWK-6 | |
| nominal cooling capacity | Kcal/h | 16340 |
| kw | 19 | |
| input power | kw | 4.65 |
| power supply | 3PH~380V/50HZ | |
| refrigerant | type | R22 |
| type of control | Expansion valve | |
| compressor | type | Hermetic scroll type |
| Power (kw) | 3.9 | |
| condenser | type | Shell and tube |
| Cooling water flow(m3/h) | 3.9 | |
| Inlet/outlet pipe caliber(inch) | 1-1/2 | |
| evaporator | type | Shell and tube |
| Chilled water flow(m3/h) | 3.3 | |
| Tank volume(L) | 60 | |
| Inlet/outlet pipe chiller(inch) | 1 | |
| Water pump | Power(KW) | 0.75 |
| Lift(m) | 20 | |
| Safety protection | compressor over temperature, over-current protection, high and low pressure protection, over -temperature protection ,flow switch protection,phase sequence or missing phase protection,exhaust overheating protection | |
| net weight | kg | 210 |
| Dimension | mm | 1250*600*1200 |
