| Brand Name: | SZAGS |
| Model Number: | AGS-200WDH |
Our Water Cooled Screw Chiller is designed with the latest technology to meet the needs of industrial refrigeration and cooling mold. With high energy efficiency and low energy consumption, this chiller offers excellent performance with low noise. It is designed to operate in ambient temperatures ranging from -10℃ to +45℃, and can provide cooling capacity of 50-1000KW. It supports a wide range of voltage levels, including 220V/380V/415V/440V/480V, and is compatible with refrigerants R22/R407C/R134A. Our Water Cooled Screw Chiller is an ideal choice for industrial refrigeration and cooling mold needs.
|
Model Item |
AGS-200WDH | |
| nominal cooling capacity | kcal/h | 643108 |
| kw | 747.8 | |
| input power | kw | 148 |
| max running current | A | 337.3 |
| power supply | 3PH-380V-50HZ | |
| refrigerant | type | R22 |
| type of control | expansion valve | |
| compressor | type | semi-hermetic screw |
| Power(kw) | 74×2 | |
| start-up mode | Y-△ | |
| capacity control | 0-25-50-75-100 | |
| evaporator | type | shell and tube |
| chilled fluid flow (m3/h) | 129 | |
| pipe diameter (inch) | 6 | |
| condenser | type | shell and tube |
| cooling water flow (m3/h) | 154 | |
| pipe diameter (inch) | 4×2 | |
| safety protection | compressor over temperature protection, over load protection, high and low pressure protection, flow switch protection, reversed and lacking phase protection, anti-freezing protection,fusible protection. | |
| dimension | mm | 4050*875*1950 |
| net weight | kg | 3460 |
| running weight | kg | 3830 |
SZAGS AGS-150WDH water cooled screw chiller is a high-performance and energy-efficient solution for cooling industrial and commercial buildings. Designed with advanced technology, this product has the capability of supplying temperature between 50 and 1000 KW with 50HZ/60HZ frequency and 3P/4P power supply. It is a perfect choice for cooling applications in water cooled chiller plant, as it has a low energy consumption and high energy efficiency. This water cooled chiller plant can effectively reduce operating costs while providing the necessary cooling for a wide range of applications. It is also easy to install and maintain, making it an ideal solution for all kinds of cooling applications.
SZAGS provides customized water cooled screw type chiller with brand model AGS-150WDH. It is the ideal choice for industrial refrigeration and cooling mold, water cooled chiller plant. It has various features such as:
SZAGS water cooled screw chiller has been designed for reliable operation and long life span. Contact us today to customize your water cooled screw chiller.
We offer comprehensive technical support and service for our Water Cooled Screw Chiller products. Our experienced technicians can help you with installation, maintenance, troubleshooting, and repairs. We are committed to providing our customers with the highest level of service and support.
Our Water Cooled Screw Chiller Technical Support Team can be contacted via email or telephone. We provide 24/7 emergency service for any urgent needs. We also offer scheduled maintenance services to help keep your system running smoothly.
Our Water Cooled Screw Chiller products are designed for reliable performance and long-term durability. We stand behind our products and offer a comprehensive warranty for all of our products.
|
|
