8 Ton 8hp Portable Air Cooled Inverter Chiller 8 Tr

8 Ton 8hp Portable Air Cooled Inverter Chiller 8 Tr

Portable Air Cooled Inverter Chiller

8hp Air Cooled Inverter Chiller

8 Tr industrial air cooled water chiller

Place of Origin:

China

Brand Name:

ANGES

Model Number:

8HP

Contact Us

Request A Quote
Product Details
Type:
Air-Cooled
Refrigerant:
R134a/R407c/R410a
Cooling Capacity:
8Ton
Compressor Type:
Inverter Scroll Chiller
Chilled Water Flow:
3.74 M³/h
Pump:
2bar
After-sales Service Provided:
Online Support, Video Technical Support, Overseas Service Center Available
Payment & Shipping Terms
Minimum Order Quantity
1
Delivery Time
25 days
Product Description

8 Ton Air Cooled Inverter Chiller 8hp Portable Water Chiller Inverter Scroll Chiller 8ton Air Water Chiller



Inverter Air Chiller- Variable Frequency

The frequency convertible scroll compressor synchronously adjust the frequency of the motor according to the change of heat load to always keep the best match, so as to ensure the machine in the best operating conditions, to to achieve the purpose of energy saving and consumption reduction which can be above 20%. Using frequency conversion drive technology, the energy efficiency of partial load of the unit has been greatly improved and the comprehensive performance coefficient (IPLV) has been improved.





ACV-8
Nominal cooling capacity Low frequency kcal/h 5182
  High frequency kcal/h 18657
  Low frequency kw 6.03
  High frequency kw 21.69
Input power Low frequency kw 3.67
  High frequency kw 8.06
Power supply Variable frequency power supply
Refrigerant Type R410a
  Type of control Electronic expansion valve
Compressor Type Hermetic motor driven compressor
  Low frequency power( kw) 1.69
  High frequency power (kw) 6.08
Condenser type Finned copper tube +low noise outer rotor fan
  power (kw) 0.48
  Cooling air flow (m3/h) 8000
Evaporator Type Water tank with coil
  Chilled water flow (m3/h) 3.74
T Tank volume(L) 120
  Inlet and outlet pipe caliber(inch) 1-1/2
Pump Power (kw) 1.5
  Lift(m) 20
Safety protection compressor over temperature, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing
Dimension mm 1530*780*1630
Weight kg 350




Features



  1. International well-known DC frequency conversion compressor is adopted for industrial frequency conversion chiller. Advanced DC frequency conversion control technology is adopted to achieve high control accuracy, and the temperature control accuracy can reach ±0.1℃-±0.2℃.
  2. High efficiency and energy saving, frequency conversion chiller energy saving than the current market ordinary industrial chiller up to 20%.
  3. The inverter scroll chiller adopts DC frequency conversion compressor control technology and electronic expansion valve throttling, so that its energy efficiency rate is more than 30% higher than the ordinary fixed frequency unit.
  4. After the variable frequency chiller is opened, the operation frequency can be automatically adjusted according to the thermal load. After the operation of the variable chiller and the load are exactly matched, the low frequency flat operation can be maintained, the system stability is further improved, the equipment failure is greatly reduced, and the service life of the equipment is prolonged.
  5. The inverter chiller adapt to a wide range of operating voltage. The chiller system can operate normally in the voltage range of ±20% to avoid the instability of industrial electricity voltage and the equipment can not run or failure.
