150HP Air Cooled Industrial Water Chiller Screw Compressor Chiller

150HP Air Cooled Industrial Water Chiller Screw Compressor Chiller

Brand Name: ANGES
Model Number: 150HP
MOQ: 1
Packaging Details: Plywood case
Payment Terms: T/T, L/C
Detail Information
Place of Origin:
China
Compressor:
Hanbell
Expansion Valve:
Emerson
Condenser:
ANGES
Evaporator:
ANGES
Solenoid Valve:
Emerson
Drying Filter:
Emerson
Oil Pressure Gauge:
REFCO
Touch Screen:
WEINTEK
PLC Controller:
Siemens
Electrical Components:
Schneider
Fan:
Maer
Highlight:

150HP air cooled industrial water chiller

,

air cooled industrial water chiller 150HP

,

150HP Screw Compressor Chiller

Product Description

Chiller System Chiller Refrigerator Industrial Chiller Screw Compressor Chiller Industrial Water Chiller Screw Chiller



Industrial water chiller system are widely used in plastic and rubber, food and beverages, medical chemistry, ultrasonic cooling, printing, electroplating, pharmaceutical and other various industrial process needs chiller service.2. An industrial chiller is a refrigeration system used to lower the temperature of machinery, industrial spaces, and process fluids by removing heat from the system and transferring it somewhere else. Industrial chillers are essential for temperature regulation in several industrial processes.



Chiller Specification

Model

Parameter

AGS-150ADH
nominal cooling capacity kcal/h 404200
  kw 470
input power kw 162
Max. Running current A 370.1
power supply 3PH~380V/50HZ
refrigerant type R22
  refrigerating circuit 1
  type of control expansion valve
compressor type semi-hermetic screw
  quantity 1
  Power 67.7×2
  start-up mode Y-△
  capacity control 0-25-50-75-100
condenser type air cooled type finned copper tube
  cooling air flow (m3/h) 155000
  power(kw) 27
evaporator type shell and tube
  quantity 1
  chilled fluid flow (m3/h) 80.8
  inlet and outlet pipe diameter (inch) 5
safety protection compressor over temperature, unit overload, high and low pressure, flow switch, phase sequence, phase-missing, anti-freezing
net weight kg 4200
Dimension mm 3150*4200*2200


Why do I need a industrial water chiller?

  1. Provide constant temperature and constant water flow chilled water to the production line, to increased production speed and ensure efficiency production.
  2. Industrial water chiller can reduce downtime and improve productivity.
  3. Decrease equipment depreciation and degradation to cut down on operating expenditures.
  4. Accurate temperature control capability, to ensure the highest quality final products.

Chiller system features:

  • Adopting high-efficiency and energy-saving compressors of world class grade brands, high-quality condensers and evaporators, high cooling efficiency, stable performance, low noise and long service life.
  • The control system is adopting Siemens PLC controller and LCD touch screen , accurately controls the cooling capacity and cooling load of the unit in real time to achieve the best matching state, to ensure that the unit runs at the best efficiency and to reduce operating costs.
  • Capacity control can adopt four-stage (100%-75%-50%-25%), three-stage (100%-66%-33%) or stepless control system.
  • High-efficiency internally threaded copper pipes enhance the heat transfer effect and are more energy-efficient and efficient.

How to select the model of the chiller ?

  • We need to know the heat load of your process or chiller cooling capacity.
  • Required water temperature, water pressure and flow rate.
  • Application and power supply in local.
  • Max. Ambient temperature in summer day
  • Customized special specifications are acceptable. Contact us for more chiller Specification by number +86 13923791048.
