Product Description:
The Industrial Water Chiller features an air-cooled cooling method, which is ideal for environments where water availability may be limited or where there are restrictions on water usage. This makes it a more environmentally-friendly option compared to traditional water-cooled chillers. With a voltage range of 220~480V, this chiller is capable of handling a wide range of power inputs, making it a versatile solution for different industrial settings.
The condenser type of this chiller is finned copper tube+low noise outer rotor fan, which ensures efficient heat transfer and low noise operation. This makes it ideal for use in noise-sensitive environments, such as laboratories or research facilities. Additionally, the Industrial Water Chiller is equipped with a high/low pressure protection system, overload protection, and phase sequence protection, ensuring that the machine operates safely and reliably.
The Industrial Water Chiller has a capacity of 46.2KW, making it suitable for use in a variety of industrial applications. It can be used as an industrial water temperature controller, industrial water cooler, or industrial water chilling machine, depending on the specific needs of your operation.
Whether you need to cool water for use in manufacturing or processing, or you need to maintain a specific temperature for your industrial equipment, the Industrial Water Chiller is the perfect solution. With its powerful cooling capabilities, efficient operation, and advanced protection systems, this chiller is a reliable and cost-effective choice for any industrial setting.
Features:
- Product Name: Industrial Water Chiller
- Noise Level: ≤65dB(A)
- Protection System: High/Low Pressure Protection, Overload Protection, Phase Sequence Protection
- Ambient Temperature: 5℃~35℃
- Frequency: 50Hz/60Hz
- Cooling Method: Air-cooled
This product is also known as an Industrial Cooler, Industrial Water Refrigerator, or Industrial Cooler.
Technical Parameters:
| Technical Parameters |
Description |
| Noise Level |
≤65dB(A) |
| Evaporator Type |
Water Tank With Coil |
| Refrigerant |
R22/R407C/R134a/R410A |
| Capacity |
46.2KW |
| Voltage |
220~480V |
| Protection System |
High/Low Pressure Protection, Overload Protection, Phase Sequence Protection |
| Frequency |
50Hz/60Hz |
| Warranty |
1 Year |
| Condenser Type |
Finned Copper Tube+low Noise Outer Rotor Fan |
| Control System |
PCB |
Applications:
With a minimum order quantity of just 1, our Industrial Water Cooler is perfect for a wide range of applications and scenarios, from small-scale industrial operations to large-scale commercial facilities. And with negotiable pricing and normal packaging details, you can be sure you're getting the best deal possible.
Our Industrial Water Chiller uses air-cooled cooling methods and is designed to operate in ambient temperatures ranging from 5℃ to 35℃, making it ideal for use in a variety of environments. And with a choice of refrigerants - including R22, R407C, R134a, and R410A - you can choose the option that best suits your needs.
The SZAGS AC-15 is equipped with a reliable scroll compressor, ensuring consistent and efficient cooling performance. And with a noise level of ≤65dB(A), you can be sure it won't disrupt your work environment.
So whether you're looking for an Industrial Water Cooler for your manufacturing facility, commercial kitchen, or any other application, the SZAGS AC-15 is the perfect choice. With a delivery time of just 35 days and a supply ability of 12,000 units per year, you won't have to wait long to start enjoying reliable and efficient cooling performance.
Specification
|
Model
|
AC-15
|
| nominal cooling capacity |
kcal/h |
39732 |
| |
kw |
46.2 |
| input power |
kw |
15.06 |
| power supply |
3PH~380V 50HZ or other power supply |
| refrigerant |
type |
R407C |
| |
type of control |
expansion valve |
| compressor |
type |
hermetic scroll |
| |
power(kw) |
12.46 |
| condenser |
type |
finned copper tube + low noise outer rotor fan |
| evaporator |
type |
shell and tube |
| |
chilled fluid flow (m3/h) |
7.97 |
| |
inlet and outlet pipe diameter (inch) |
2 |
| pump |
power (kw) |
1.5 |
| |
lift(m) |
20 |
| safety protection |
compressor over temperature, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing |
| dimension |
mm |
1900*1050*1800 |
| weight |
kg |
750 |
The nominal cooling capacity is according to: Inlet chilled fluid temperature: 17℃,outlet chilled fluid temperature: 12℃Note:
Features of chiller cooling system
- The small water chiller use scroll compressor, high refrigeration efficiency, excellent performance.
- The COP efficiency of air cooled water chiller is about 3.3. According to the industrial needs, it can be refrigerated or heated, which is more used in general laboratories and small production lines.
- The COP efficiency of water-cooled chiller is relatively high, about 4-5.5, which is used in industrial process cooling and large-scale construction projects.
- Compared with the high efficiency wate cooled chiller, the air-cooled chiller is only different from the condenser. The air-cooled chiller dissipates heat directly through the fan, while the water-cooled chiller takes away the heat from the condenser through cold water and dissipates heat through the cooling tower.
- The water cooled low temperature water chiller can only refrigeration, if the need for heating, need other heating equipment.
