| Brand Name: | SZAGS/Anges |
| Model Number: | AGS-100ADH |
| MOQ: | 1 |
| Price: | Negotiatible |
| Packaging Details: | Standard export wooden box |
| Payment Terms: | T/T, L/C, MoneyGram |
|
Model |
AGS-100ADH | |
| nominal cooling capacity | kcal/h | 282080 |
| kw | 328 | |
| input power | kw | 93 |
| max running current | A | 211.5 |
| power supply | 3PH 380V 50Hz | |
| refrigerant | type | R407C |
| refrigerating circuit | 2 | |
| weight(kg) | 70 | |
| type of control | thermostatic expansion valve | |
| compressor | type | semi-hermetic screw |
| power(kw) | 37.4×2 | |
| quantity | 2 | |
| start-up mode | Y-△ | |
| capacity control | 0-25-50-75-100 | |
| condenser | type | air cooled high-efficient inner threaded copper-tubing aluminum fin type |
| cooling air flow (m3/h) | 105000 | |
| power(kw) | 18 | |
| evaporator | type | shell and tube |
| quantity | 2 | |
| chilled fluid flow (m3/h) | 80.8 | |
| inlet and outlet pipe diameter (inch) | 5" | |
| safety protection | compressor over temperature protection, over load protection, high and low pressure protection, flow switch protection, reversed and lacking phase protection, anti-freezing protection. | |
| dimension | Length(mm) | 4200 |
| Width(mm) | 2200 | |
| Height(mm) | 2383 | |
| net weight | kg | 3340 |
| running weight | kg |
3540 |
Note: The nominal cooling capacity is according to: Inlet chilled fluid temperature: 17℃,outlet chilled fluid temperature: 12℃.
1.Fast Response: Air-cooled screw chillers can quickly adjust cooling capacity to meet instantaneous load changes, enhancing system flexibility.
2.Environmentally Friendly: SZAGS air-cooled screw chillers use environmentally friendly refrigerants, reducing environmental impact and complying with modern eco-friendly requirements.
3.Easy Operation: User-friendly control systems simplify operation and monitoring, reducing reliance on specialized personnel.
4.High Durability: SZAGS Air-cooled screw chillers are made of high-quality materials and designs, offering a long service life and reducing replacement frequency.
5.Energy-Saving Options: SZAGS air-cooled screw chillers are designed with capacity control range 0-25-50-75-100%, which automatically adjusts operating speed based on actual load, further saving energy.
6.Suitable for Various Industrial Applications: SZASG Air-cooled screw chillers are widely used in chemical, food processing, pharmaceutical, and plastic manufacturing industries, demonstrating strong adaptability.
①24 hours Online support;
②Video guide;
③Overseas third-party support available and etc.
|
|
