100ton Air-Cooled Screw Chiller Using For Extruder And Laser Cleaning Machine

100ton Air-Cooled Screw Chiller Using For Extruder And Laser Cleaning Machine

Extruder Air Cooled Screw Chiller

100ton Air Cooled Screw Chiller

Place of Origin:

China

Brand Name:

SZAGS

Model Number:

AGS-100ADH

Contact Us

Request A Quote
Product Details
Compressor Type:
Semi-hemetic Crew
Cooling Mode:
Air Cooling
Condenser:
Air-cooled High Efficient Inner Threaded Cooper Tube Aluminum Fin Type
Dimension:
4200*2200*2383mm
Compressor Brand:
Bitzer/Hanbell
Evaporator:
Shell And Tube/Plate Heat Exchanger
Warranty:
1 Year
Product Name:
Grey Screw Type Chiller
Payment & Shipping Terms
Minimum Order Quantity
1
Price
negotiated
Packaging Details
plywood box
Delivery Time
25 days
Payment Terms
L/C, T/T
Supply Ability
20 units per month
Product Description

100ton air cooled screw chiller Industrial chiller water cooling systems for Extruder laser cleaning machine

Screw Type Chiller is an efficient and reliable water chiller that provides cooling solutions for various commercial and industrial applications. It is powered by a 380V/50Hz power supply and comes with a PLC controller for easy operation and maintenance. The chiller also comes with a selection of refrigerants such as R22, R134a, R407c, and R410a, and is equipped with a range of compressor brands including Bitzer, Copeland, and Hanbell. This Screw Type Chiller is designed to provide superior cooling performance with low energy consumption, making it an ideal cooling solution for any industry or space. It is also highly reliable and requires minimal maintenance.



Technical Parameters:

Model
Parameter

AGS-100ADH
nominal cooling capacitykcal/h282080
kw328
input powerkw81
Max. Running currentA184.1
power supply3PH/220~480V/50~60HZ
refrigeranttypeR22/R407C/R134A/410A
refrigerating circuit2
type of controlthermostatic expansion valve
compressortypesemi-hermetic screw
quantity2
Power74.8
start-up modeY-△
capacity control0-25-50-75-100
condensertypeair cooled high efficient inner threaded  copper tube aluminum fin
cooling air flow (m3/h)105000
power(kw)6
evaporatortypeshell and tube/plate
quantity1
chilled fluid flow (m3/h)56.4
inlet and outlet pipe diameter (inch)4"
safety protectioncompressor over temperature, unit overload, high and low pressure, flow switch, phase sequence, phase-missing, anti-freezing
net weightkg3340
Dimensionmm4200*2200*2383



Features:

  • Product Name: Screw Type Chiller
  • Warranty: 1 Year
  • Cooling Mode: Air/Water
  • Refrigerant: R22/R134a/R407c/R410a
  • Cooling Capacity: 100ton
  • Controller: PLC
  • Mainly used for extruder laser cleaning machine
  • Air cooled chiller


Applications:

The SZAGS AGS-100ADH Screw Type Chiller is the perfect solution for your plastics industry needs. It is an energy-efficient cooling device that provides precise temperature control to maintain optimum efficiency. With a cooling capacity ranging from 150-1000kW and a noise level of ≤75dB(A), this chiller ensures reliable and efficient cooling with a 1-year warranty. The condenser and evaporator both use Shell and Tube and Plate Heat Exchanger designs to further enhance the energy-saving capabilities of this product. This Screw Type Chiller is specially designed to be used in the plastics industry to provide energy-efficient cooling solutions.



Customization:

SZAGS AGS-100ADH Screw Type Chiller offers a wide range of cooling capacity from 150-1000kW and can be customized to fit your needs. It is widely used for plastics industry and provides powerful cooling capacity to meet the demands of production. It is designed for 380V/50Hz power supply and can be used for both air and water cooling. Plus, it guarantees a noise level of ≤75dB(A).



Support and Services:

Screw Type Chiller Technical Support and Service

We provide technical support and service to ensure that our customers have the best experience with our Screw Type Chiller product. Our team of experienced engineers and technicians is available to answer any questions or concerns you may have about the product.
We offer on-site installation and maintenance services to ensure that your Screw Type Chiller is running smoothly and efficiently. Our technicians have the experience and expertise to diagnose any issues quickly and provide solutions that will ensure the optimal performance of your unit.
We also offer a comprehensive warranty package to cover any defects or malfunctions in the product. Our warranty includes parts and labor costs, and we are committed to providing prompt and professional service.
Finally, we offer a variety of customer support options, including phone, email, and online support. Our customer service team is available 24 hours a day, 7 days a week to provide assistance and answer any questions you may have.



Packing and Shipping:

Packaging and Shipping of Screw Type Chiller

Screw Type Chiller is packaged in a suitable wooden box or carton for protection during transit. The box or carton is sealed with adhesive tape and labeled with the product name, part number and other relevant information. The product is then shipped to the customer according to their requirements.



FAQ:

Q: What is Screw Type Chiller?
A: Screw Type Chiller is a kind of air-cooled chiller with advanced technology, produced by SZAGS. It is mainly used to cool and circulate water or other liquids in industrial process.
Q: What is the Brand Name and Model Number of Screw Type Chiller?
A: The Brand Name is SZAGS, and the Model Number is AGS-100ADH
Q: Where is Screw Type Chiller produced?
A: Screw Type Chiller is produced in China.
Q: What are the benefits of using Screw Type Chiller?
A: The advantages of Screw Type Chiller are energy saving, environmental protection, low noise, high efficiency, and easy installation and maintenance.
Q: What is the cooling capacity of Screw Type Chiller?
A: The cooling capacity of Screw Type Chiller is from 100kW to 4920kW.
