Place of Origin:
China
Brand Name:
ANGES
Model Number:
100hp
Contact Us
| Item | AGS-100WSHI | |
| nominal cooling capacity | kcal/h | 281134 |
| kw | 326.9 | |
| input power | kw | 95 |
| max running current | A | 216.5 |
| power supply | 3PH-380V-50HZ | |
| refrigerant | type | R22 |
| type of control | expansion valve | |
| compressor | type | semi-hermetic screw |
| Power(kw) | ||
| start-up mode | Y-△ | |
| capacity control | 0-25-50-75-100 | |
| evaporator | type | shell and tube |
| chilled fluid flow (m3/h) | 56.2 | |
| pipe diameter (inch) | 4" | |
| condenser | type | shell and tube |
| cooling water flow (m3/h) | 80.4" | |
| pipe diameter (inch) | 4" | |
| safety protection | compressor over temperature protection, over load protection, high and low pressure protection, flow switch protection, reversed and lacking phase protection, anti-freezing protection,fusible protection. | |
| Tank | L | 3000 |
| External circulation pump | Power(kw) | 7.5 |
| Lift(m) | 23.6 | |
| Internal circulation pump | Power(kw) | 7.5 |
| Lift(m) | 22 | |
| dimension | mm | 3600*2250*2400 |
| net weight | kg | 2360 |
| running weight | kg | 5560 |
1. Brand semi-close double-screw compressor and long service-life of bearing ensure long time operation, and it is
equipped with high-efficient motor that gives compressorhigh efficiency.
2. The condenser and evaporator both can meet therequirement of national standard, with high-effcient heattransfer effect, convenient service and maintenance.
3. Equipped with programmable logical controller to control viapanel for convenient adjustment.
4. Step-less compressor can achieve a cooling output range ot50~100% with each compressor and realize stable cooling output.
5. Standard equipped with high and low pressure switchfusible plug. overload protector, coil overheat protector.exhaust air overheat protection, cooling water overheat and large temperature deviation protection.
Water chiller service from manufacturer
We are industrial chiller manufacturer, chiller service can be online support, video technical support, site service in some areas are available.
Site service will be done by our water chiller distributor, Indonesia, Philippines, Thailand, Singapore, Malaysia, Australia, United States, Israel, Egypt and so on.
1.All the chillers are provided with 12 months free maintenance service.
2.Provide technical explanation, chiller debugging support, technical training and chiller maintenance guidance.
3.If necessary, after-sales engineers can be on-site service confirmed by both parties through communication .In some areas, local dealers can provide fast and convenient service.
4.Provide the air chiller and water chiller required parts quickly to ensure the normal use of customers.If necessary, part of the wearing parts can be provided for backup after confirmation by both parties.
5.Chiller maintenance service outside the warranty period, life-long tracking maintenance, cost price to provide equipment parts.
