| Brand Name: | ANGES |
| Model Number: | 10HP |
| MOQ: | 1 |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T, L/C, T/T, L/C |
10ton water cooled scroll chiller 10HP Water Cooled Industrial Chiller Water Chilling Plant
Anges chiller is divided into two types: Air-cooled chiller and Water-cooled chiller.
Water chiller is divided into a low-temperature chiller and a normal-temperature chiller in temperature control.
The normal temperature is generally controlled the water within the range of 0 to 35 degrees.
The temperature control of the cryostat is generally in the range of 0 degrees to minus 30 degrees.
Specification for chilled water system
|
Model Item |
AWK-10(D) | |
| nominal cooling capacity | Kcal/h | 29240 |
| kw | 31.6 | |
| input power | kw | 8.1 |
| power supply | 3PH~380V/50HZ | |
| refrigerant | type | R22 |
| type of control | Expansion valve | |
| compressor | type | Hermetic scroll type |
| Power (kw) | 6.6 | |
| condenser | type | Shell and tube |
| Cooling water flow(m3/h) | 6.5 | |
| Inlet/outlet pipe caliber(inch) | 1-1/2 | |
| evaporator | type | Shell and tube |
| Chilled water flow(m3/h) | 5.4 | |
| Tank volume(L) | 75 | |
| Inlet/outlet pipe chiller(inch) | 1-1/2 | |
| Water pump | Power(KW) | 1.5 |
| Lift(m) | 20 | |
| Safety protection | compressor over temperature, over-current protection, high and low pressure protection, over -temperature protection ,flow switch protection,phase sequence or missing phase protection,exhaust overheating protection | |
| net weight | kg | 500 |
| Dimension | mm | 1320*800*1320 |
Benefits of an industrial water chiller
Chiller Unit Features and Advantages:
Why Choose Us
|
|
