120HP Water Cooled Industrial Chiller Industrial Water Chiller

Place of Origin China
Brand Name ANGES
Model Number 120HP
Minimum Order Quantity 1
Packaging Details Plywood case
Delivery Time 30 days
Payment Terms T/T, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Certification CE,ISO9001 Type Air-cooled/water Chiller/unit
Cooling Capacity 351kw Condition Brandnew
Refrigerant R22, R134A, R407C Compressor Screw,single Compressor
Evaporator Tube In Shell Evaporator Condenser Air-cooled Fin Condenser
After-sales Service Provided Online Support,Video Technical Support,Overseas Third-party Support Available
High Light

120HP Water Cooled Industrial Chiller

,

Water Cooled Industrial Chiller Industrial

,

120HP industrial water chiller

Leave a Message
Product Description

Water Chiller Central Chiller Screw Compressor Chiller Unit Water Cooled Water Chiller Water Chilling Plant



Water screw chiller - efficient industrial cooling

Screw chiller capactiy range is from 140kw to 760kw, water cooling temperature if adjustable 5 - 30 ℃.The screw chiller compressor is See our screw chiller catalogue for more details.


High efficiency chiller units engineered for heavy-duty industrial applications. The units are equipped with world class components, including high efficiency screw compressors. The screw type chillers have simple structure, fewer moving parts and wear parts, ensuring less noise and more reliable operation. Stepless variable-speed control can be achieved within a range of 10%-100%, improving energy efficiency.



Air-cooled screw chiller specification

Model

AGS-120ADH
nominal cooling capacity kcal/h 302376
  kw 351
input power kw 112
max running current A 255
power supply 3PH~380V 50HZ
refrigerant type R22
  refrigerating circuit 2
  type of control thermostatic expansion valve
compressor type semi-hermetic screw
  kw 47*2
  start-up mode Y-△
  capacity control 0-25-50-75-100
condenser type air cooled type finned copper tube
  cooling air flow (m3/h) 122000
  Power(kw) 18
evaporator type shell and tube
  quantity 1
  chilled fluid flow (m3/h) 61
  inlet and outlet pipe diameter (inch) 5
safety protection compressor over temperature, unit overload, high and low pressure, flow switch, phase sequence, phase-missing, anti-freezing
net weight kg 3850
Dimension mm 4400*2200*2420


Air-cooled screw chiller featurers

  1. Adjustable water temperature: Air cooled Screw chillers are large cooling capacity from 120kw and 760kw. The chilled water temperature provided is within a range of 5℃-30℃.
  2. Stable performance: This chiller used two compressors, and each compressor has an independent refrigeration circuit. All compressors are under the command of a unified microcomputer control system, which can be turned on and off one by one without interfering with each other. The machine is all made of original and genuine products, single machine failure rate is very low. Considering the above reasons, the machine can be guaranteed to have a highly stable performance.
  3. Power saving and energy saving: Screw chiller compressor capacity control can be used in four stages (100%-75%-50%-25%) or three stages (100%-66%-33%) and no stage control system in the best working condition, so as to effectively save energy.
  4. Long service life: Shell and tube evaporator and condenser, the welded structure is simple, sturdy structure, high quality, compact structure, long life and so on.
  5. Lower installation cost : Air-cooled screw chiller does not need to be equipped with cooling pump, cooling tower and other auxiliary equipment, can save a lot of materials and engineering installation costs, and even do not need to set up the machine room.
  6. Simple operation: Air-cooled screw chillers equipped with man-machine interface equipped with large screen touch screen, to realize man-machine intelligent dialogue. Multi-language display of unit running status, automatic detection of unit failure, convenient operation and management.

Benefits of industrial chiller

  • Lower operational costs and save time
  • High energy efficiency and save water
  • High reliability and easy maintance
  • Lifetime warranty

Water chiller service from manufacturer

  1. All the chillers are provided with 12 months free maintenance service.
  2. Provide technical explanation, chiller debugging support, technical training and chiller maintenance guidance.
  3. If necessary, after-sales engineers can be on-site service confirmed by both parties through communication .In some areas, local dealers can provide fast and convenient service.
  4. Provide the air chiller and water chiller required parts quickly to ensure the normal use of customers.If necessary, part of the wearing parts can be provided for backup after confirmation by both parties.
  5. Chiller maintenance service outside the warranty period, life-long tracking maintenance, cost price to provide equipment parts.
