Name: 150ton Air Cooled Screw Chiller for Industrial Processes cooling milk chiller unit
Brand: Shenzhen Anges Machinery Co., Ltd
SKU: 150HP
Price: 2,100.00 USD
Availability: InStock

Home > Products > Screw Type Chiller >

150ton Air Cooled Screw Chiller for Industrial Processes cooling milk chiller unit

150ton Air Cooled Screw Chiller

Place of Origin:

China

Brand Name:

ANGES

Model Number:

150HP

Request A Quote

150ton Air Cooled Screw Chiller for Industrial Processes cooling milk chiller unit

Product Details

Compressor:

Hanbell

Expansion Valve:

Emerson

Condenser:

ANGES

Evaporator:

ANGES

Solenoid Valve:

Emerson

Drying Filter:

Emerson

Oil Pressure Gauge:

REFCO

Touch Screen:

WEINTEK

PLC Controller:

Siemens

Electrical Components:

Schneider

Fan:

Nangbeng

Highlight:

150ton Air Cooled Screw Chiller

Payment & Shipping Terms

Minimum Order Quantity

Packaging Details

Plywood case

Delivery Time

30 days

Payment Terms

T/T, L/C

40HP air-cooled screw industrial chiller with a cooling capacity of 124.6KW is suitable for rapid cooling of milk, beverage filling lines and dairy product processing.

Get Best Price

60hp Water-cooled Screw Type Chiller Use For Plastic Machine

Get Best Price

85HP Industrial Air-Cooled Screw Chiller Energy-Saving Cooling Solution for Extrusion

Get Best Price

170HP Inverter Air-cooled Screw Type Water Chiller for Industrial Cooling

Get Best Price

86-755-8958-2358

Contact Now

Product Description

150ton Air Cooled Screw Chiller for Industrial Processes cooling milk chiller unit Chiller Industrial Chiller Suppliers

Air Cooled Screw Type Central Chiller cool the milk on the farm

This Air-cooled screw central chiller is perfect choice that use for plastic process, such as plastic injection, plastic extruding, bottle blowing, film blowing and son on.The industrial chiller used to transfer heat away from the mold, it can accurately controls the cooling time in injection molding is a critical part of the production process.

An air cooled chiller is used where discharge is not a problem. It absorbs heat from water and transfers it into the air: first, heat from the circulating chilled water is absorbed in the evaporator, and then the refrigerant condenses in the condenser and releases the heat into the air.

Process Chiller Injection Molding Specification

Model Parameter		AGS-150ADH
nominal cooling capacity	kcal/h	404200
	kw	470
input power	kw	162
Max. Running current	A	370.1
power supply	3PH~380V/50HZ
refrigerant	type	R22
	refrigerating circuit	1
	type of control	expansion valve
compressor	type	semi-hermetic screw
	quantity	1
	Power	67.7×2
	start-up mode	Y-△
	capacity control	0-25-50-75-100
condenser	type	air cooled type finned copper tube
	cooling air flow (m³/h)	155000
	power(kw)	27
evaporator	type	shell and tube
	quantity	1
	chilled fluid flow (m³/h)	80.8
	inlet and outlet pipe diameter (inch)	5
safety protection	compressor over temperature, unit overload, high and low pressure, flow switch, phase sequence, phase-missing, anti-freezing
net weight	kg	4200
Dimension	mm	315042002200

Features:

Adopting high-efficiency and energy-saving compressors of world class grade brands, high-quality condensers and evaporators, high cooling efficiency, stable performance, low noise and long service life.
The control system is adopting Siemens PLC controller and LCD touch screen , accurately controls the cooling capacity and cooling load of the unit in real time to achieve the best matching state, to ensure that the unit runs at the best efficiency and to reduce operating costs.
Capacity control can adopt four-stage (100%-75%-50%-25%), three-stage (100%-66%-33%) or stepless control system.
High-efficiency internally threaded copper pipes enhance the heat transfer effect and are more energy-efficient and efficient.

Some distinctive features of Air-cooled central screw type chillers:

Lower installed cost.The central screw chiller system contains refrigeration circuit, reservoir, pumps, and necessary components to work for multiple process throughout a plant, less pipes installation.
Convenience of installation and service.This air cooled central no need cooling tower installation, and water treatment, chiller condenser-tube cleaning, tower mechanical maintenance.
Simple operation. No need to operate multiple chiller units for different process one by one.
High Efficiency.The central chiller system continuously measures ambient and process conditions and will adjust to operate in the most efficient manner.

Anges service

After sale service: All of our machine provide long time after-sale service .
We accept OEM orders, processing according to buyer’s samples or drawing
On-time shipment
Product quality protection
Payment protection.
