60HP water cooler industrial chiller Portable Chiller water cooled chiller to cooling Injection Molding Machine
| Place of Origin | China |
|---|---|
| Brand Name | ANGES |
| Model Number | 60HP |
| Minimum Order Quantity | 1 |
| Packaging Details | Plywood case |
| Delivery Time | 25 days |
| Payment Terms | T/T, L/C, T/T, L/C |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Water-cooled Type | Cooling Capacity | 204 Kw |
|---|---|---|---|
| Compressor | 60 Hp | Condenser | Shell And Tube |
| Evaporator | Shell And Tube | Voltage | 3PH~220V/380V/415V~50HZ/60HZ |
| Condition | Brand New | Dimension(l* W*h) | 2800*1400*1950 Mm |
| Warranty | 12 Months | Refrigerant | R22/R134a/R407C/R410a |
| Weight | 1800kg | Temperature | 5℃~30℃ |
Product Description
water cooler industrial chiller 60tr Portable Chiller Water Cooled Scroll Chiller 60HP Water Cooled Industrial Chiller Water Chilling Plant
Water cooled chiller
Anges chiller is divided into two types: Air-cooled chiller and Water-cooled chiller.
Water chiller is divided into a low-temperature chiller and a normal-temperature chiller in temperature control.
The normal temperature is generally controlled the water within the range of 0 to 35 degrees.
The temperature control of the cryostat is generally in the range of 0 degrees to minus 30 degrees.
Specification for chilled water system
|
Model Item |
AWK-60(F) | |
| nominal cooling capacity | Kcal/h | 175440 |
| kw | 204 | |
| input power | kw | 44.8 |
| power supply | 3PH~380V/50HZ | |
| refrigerant | type | R22/R134a/R407c |
| type of control | Expansion valve | |
| compressor | type | Hermetic scroll type |
| Power (kw) | 40.8 | |
| condenser | type | Shell and tube |
| Cooling water flow(m3/h) | 42.2 | |
| Inlet/outlet pipe caliber(inch) | 4 | |
| evaporator | type | Shell and tube |
| Chilled water flow(m3/h) | 35.2 | |
| Tank volume(L) | 480 | |
| Inlet/outlet pipe chiller(inch) | 3 | |
| Water pump | Power(KW) | 4 |
| Lift(m) | 22 | |
| Safety protection | compressor over temperature, over-current protection, high and low pressure protection, over -temperature protection ,flow switch protection,phase sequence or missing phase protection,exhaust overheating protection | |
| net weight | kg | 1800 |
| Dimension | mm | 2800*1400*1950 |
Featurers for portable water cooled scroll chiller
- This 40Tr water chiller use four refrigerant circuits with 4 units famous brand scroll compressor.Scroll compressor has the advantages of small volume, low noise, light weight, small vibration, low energy consumption, long life and reliable operation.
- This 40ton water cooled chiller can be a central chiller to cool several processes,easy installation and operation with lower cost.
- High efficient shell and tube type evaporator,built-in stainless steel 304 water tank,easy to install and use.
- The shell and tube condenser is low condensing temperature, good cooling effect, suitable for medium and large refrigeration system.It can run easily even in hot weather.
- This industrial water-cooled chiller equipped with figure intellectualized temperature controls, which can accurately measure and control water temperature within the range of 5C-30C.
- This chiller protection system includeds compressor overheat protection, high/low pressure protection, phase missing/sequence protection, flow rate protection, anti-frozen protection.
Benefits of an industrial water chiller
- The ability to maintain constant and precise control of the process temperature.
- The cooling fluid can be delivered directly to the application heat source to increased production speed and ensure efficiency production
- Accurate temperature control capability, to ensure the highest quality final products.
- Water chiller systems prevent damage to heat-sensitive industrial components preventing undesirable repair downtime that might slow or even halt production altogether.
FULL-SERVICES:
- 12Months warranty and technical maintenance offered.
- Professional technical team and sales person give you regarding troubleshooting procedures via Internet and Phone any time when needed.
- All extra parts for the machine can be purchased with good price
- 24 Hours working phone call/Email/Wechat/Whatsapp to support.
